Monocrystalline Solar Panels
| Part Number | Wattage (W) | Open Circuit Voltage (Voc) | Short Circuit Current (Isc) | Maximum Power Voltage (Vm) | Maximum Power Current (Im) | Number of Cells | Solar Cell Dimensions | Dimensions | Weight | Operating Temperature (°C) | Mechanical Load | Series Fuse Rating (Max) | Number of Diodes | System Voltage (Max) | Waterproof Protection (IP Rate) | Number of Draining Holes | Glass Type | Glass Thickness | Frame Material | Connector | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 020406020 | |
100W | 22.7V | 5.8A | 18.35V | 5.45A | 36(4×9) | 125×125 | 1195×541×35mm | 7.6kgs | 45 | 2400Pa | 10A | 2 | 1000VDC | IP65 | 4 | Tempered | 3.2mm | |
|
| 020406017 | |
150W | 22.5V | 8.85A | 18.2V | 8.25A | 36(4×9) | 156×156 | 1482×676×35mm | 11.1kgs | 45 | 2400Pa | 15A | 2 | 1000VDC | IP65 | 4 | Tempered | 3.2mm | |
|
| 020406026 | |
170W | 23.6V | 9.45A | 19.21V | 8.85A | 36(4x9) | 156.75×156.75mm | 1478×678×30mm | |
45 | |
15A | 2 | 1000V/DC | |
4 | Tempered | 3.2mm | |
|
| 020406032 | |
190W | 24.2V | 10.05A | 20.3V | 9.36A | 36(4x9) | 158.75×158.75mm | 1500×676×30mm | |
45 | |
15A | 2 | 1000V/DC | IP65 | 4 | Tempered | 3.2mm | Alluminum | MC4 |
| 020406021 | |
200W | 45.4V | 5.8A | 36.7V | 5.45A | 72(6×12) | 125X125 | 1580×808×35mm | 13.5kgs | 45 | 2400Pa | 15A | 3 | 1000VDC | IP67 | 4 | Tempered | 3.2mm | |
|
| 020406018 | |
250W | 36.8V | 8.75A | 30.9V | 8.1A | 60(6×10) | 156×156 | 1640×992×35mm | 19.5kgs | |
|
|
|
|
|
|
|
3.2mm | |
|
| 020406022 | |
260W | 37V | 8.92A | 31.35V | 8.3A | 72(6×12) | 156×156 | 1640×992×40mm | 19.5kgs | 45 | 2400Pa | 15A | 3 | 1000VDC | IP67 | 4 | ARC | 3.2mm | |
|
| 020406024 | |
270W | 38.3V | 9.03A | 31.22V | 8.65A | |
|
1650×990×35mm | |
|
|
|
|
1000VDC | |
|
|
3.2mm | |
|
| 020406016 | |
300W | 44.8V | 8.7A | 37V | 8.1A | 72(6×12) | |
1956×992×45mm | |
|
|
|
3 | |
|
|
|
3.2mm | |
|
| 020406025 | |
370W | 48.3V | 9.95A | 40.1V | 9.23A | 72(6×12) | 156.75×156.75mm | 1956×992×40mm | 21.5kgs | 25 | 2400Pa | 15A | 3 | 1000VDC | IP68 | 4 | Tempered Glass | 3.2mm | |
|
| 020406029 | |
390W | 49.3V | 10.12A | 41.1V | 9.49A | 72 | 158.75×158.75mm | 1979×1002×40mm | 22.5kgs | 25 | 2400PA | 15A | 3 | 1000VDC | IP68 | 4 | Tempered Glass | 3.2mm | |
|
| 020406030 | |
440W | 48.9V | 11.46A | 41.1V | 10.71A | 144 | 6×24 | 2108×1048×35mm | 24kg | -40°C - +85°C | 2400Pa | 20A | 3 | 1500V/DC | IP68 | |
Low-Iron Tempered Glass | 3.2mm | |
|
| 020406033 | |
450W | 49.3V | 11.6A | 41.5V | 10.85A | 144 | 166×82mm | 2096×1039×30mm | 24kgs | -40°C...+85°C | 5400PA | 20A | 3 | 1500V | IP68 | 4 | Low-Iron Tempered Glass | 3.2mm | Aluminum | Junction Box |
| 020406034 | |
540W | 49.5V | 13.85A | 41.65V | 12.97A | 144 | 182×91mm | 2256×1133×35mm | 27.2kgs | -40°C...+85°C | 5400PA | 25A | 3 | 1500V | IP68 | 4 | Low-Iron Tempered Glass | 3.2mm | Aluminum | Junction Box |
| 020406037 | |
450W | 49.3V | 11.6A | 41.5V | 10.85A | 144 | 166×82mm | 2096×1039×30mm | 24kgs | -40°C...+85°C | 5400PA | 20A | 3 | 1500V | IP68 | 4 | Low-Iron Tempered Glass | 3.2mm | Aluminum | Junction Box |
| 020406038 | |
540W | 49.5V | 13.85A | 41.65V | 12.97A | 144 | 182×91mm | 2256×1133×35mm | 27.2kgs | -40°C...+85°C | 5400PA | 25A | 3 | 1500V | IP68 | 4 | Low-Iron Tempered Glass | 3.2mm | Aluminum | Junction Box |
| 020406019 | |
50W | 22.5V | 2.95A | 18.2V | 2.75A | 36(4×9) | 52×156 | 532×674×30mm | 3.8kgs | 45 | |
10A | 2 | 1000VDC | IP65 | 4 | Tempered | 3.2mm | |
|
